NCP5203MNR2
RoHS
RoHS compliant
RoHS compliantPackage 18-VFDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Special Purpose
Description
SWITCHING CONTROLLER
PDF
/
Buying Options
Total Price: USD $14.91
Unit Price: USD $14.91215
≥1 USD $14.91215
≥10 USD $12.236
≥100 USD $11.85315
≥500 USD $11.47125
≥1000 USD $11.0884
Inventory: 10907
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 5mm
Length 6mm
Height Seated (Max) 1mm
Technical
Switching Frequency-Max 700kHz
Switcher Configuration PUSH-PULL
Control Technique PULSE WIDTH MODULATION
Control Mode VOLTAGE-MODE
Voltage - Input 4.5V~5.5V
Analog IC - Other Type SWITCHING CONTROLLER
Input Voltage-Nom 5V
Qualification Status COMMERCIAL
Number of Outputs 2
JESD-30 Code R-PDSO-N18
Pin Count 18
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) 235
Terminal Form NO LEAD
Terminal Position DUAL
Applications Controller, DDR
Terminal Finish TIN
Number of Terminations 18
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Surface Mount YES
Package / Case 18-VFDFN Exposed Pad
Mounting Type Surface Mount
