ISL6523CBZ-T
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Special Purpose
Description
DUAL SWITCHING CONTROLLER
PDF
/
Buying Options
Total Price: USD $4.51
Unit Price: USD $4.5056
≥1 USD $4.5056
Inventory: 1196
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.5mm
Length 17.9mm
Height Seated (Max) 2.65mm
Technical
Switching Frequency-Max 215kHz
Switcher Configuration PUSH-PULL
Control Technique PULSE WIDTH MODULATION
Control Mode VOLTAGE-MODE
Voltage - Output Multiple
Voltage - Input 5V~15V
Analog IC - Other Type DUAL SWITCHING CONTROLLER
Input Voltage-Nom 12V
Number of Outputs 4
JESD-30 Code R-PDSO-G28
Pin Count 28
Time@Peak Reflow Temperature-Max (s) 40
Reach Compliance Code unknown
Terminal Pitch 1.27mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Applications Controller, Intel VRM8.5
Terminal Finish MATTE TIN
Number of Terminations 28
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Surface Mount YES
Package / Case 28-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Alternative Model
