ISL6425ERZ
RoHS
RoHS compliant
RoHS compliantPackage 32-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Special Purpose
Description
SWITCHING CONTROLLER
PDF
/
Buying Options
Total Price: USD $5.09
Unit Price: USD $5.0864
≥1 USD $5.0864
Inventory: 1863
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 5mm
Length 5mm
Height Seated (Max) 1mm
Technical
Switcher Configuration SINGLE
Control Technique PULSE WIDTH MODULATION
Output Current-Max 0.95A
Control Mode CURRENT-MODE
Voltage - Output 13V~18V
Voltage - Input 8V~14V
Analog IC - Other Type SWITCHING CONTROLLER
Input Voltage-Nom 12V
Number of Outputs 2
Pin Count 32
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Applications Converter, Satellite Set-Top Box Designs
Terminal Finish MATTE TIN
Number of Terminations 32
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Packaging Tube
Operating Temperature -20°C~85°C
Physical
Surface Mount YES
Package / Case 32-VFQFN Exposed Pad
Mounting Type Surface Mount
