RC1587M
RoHS
/
Package TO-263-4, D2Pak (3 Leads + Tab), TO-263AA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Special Purpose
Description
IC REG CONV PENTIUM 1OUT TO263-3
PDF
/
Buying Options
Total Price: USD $2.09
Unit Price: USD $2.09475
≥1 USD $2.09475
≥10 USD $1.7195
≥100 USD $1.66535
≥500 USD $1.6112
≥1000 USD $1.558
Inventory: 8005
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Technical
Input-Output Voltage Differential-Max 5.75V
Line Regulation-Max (%/V) 0.067
Load Regulation-Max(%) 0.3%
Input Bias Current 4mA
Dropout Voltage1-Nom 1.15V
Dropout Voltage 1.3V
Reference Voltage 1.275V
Max Input Voltage 7V
Voltage - Output 1.5V~3.6V
Output Current 3A
Voltage - Input 4.5V~7V
Output Type Adjustable
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-PSSO-G3
Base Part Number RC1587
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position SINGLE
Technology BIPOLAR
Max Power Dissipation 18W
Subcategory Other Regulators
Applications Converter, Intel Pentium? II GTL+, Pro
Terminal Finish Tin/Lead (Sn/Pb)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Packaging Tube
Operating Temperature 0°C~125°C
Physical
Package / Case TO-263-4, D2Pak (3 Leads + Tab), TO-263AA
Mounting Type Surface Mount
Mount Surface Mount
