NCP5381AMNR2G
RoHS
/
Package 40-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Special Purpose
Description
IC BUCK CTLR 2/3/4PHASE 40-QFN
PDF
/
Buying Options
Total Price: USD $4.81
Unit Price: USD $4.80985
≥1 USD $4.80985
≥10 USD $3.9463
≥100 USD $3.82375
≥500 USD $3.70025
≥1000 USD $3.57675
Inventory: 4002
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 6 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 40-VFQFN Exposed Pad
Number of Pins 40
Technical
Operating Temperature 0°C~70°C
Packaging Tape & Reel (TR)
Published 2008
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 40
ECCN Code EAR99
Terminal Finish Tin (Sn)
Applications Controller, Intel Pentium? IV
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 0.5mm
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number NCP5381
Pin Count 40
Number of Outputs 4
Qualification Status Not Qualified
Input Voltage-Nom 12V
Analog IC - Other Type SWITCHING CONTROLLER
Voltage - Input 10.8V~13.2V
Control Technique PULSE WIDTH MODULATION
Switcher Configuration PUSH-PULL
Switching Frequency-Max 1000kHz
Dimensions
Height Seated (Max) 1mm
Length 7mm
Width 7mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
