NCP5218MNR2G
RoHS
/
Package 22-VFDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Special Purpose
Description
IC DDR PWR CTLR 2IN2 NTBK 22-DFN
PDF
/
Buying Options
Total Price: USD $13.85
Unit Price: USD $13.85005
≥1 USD $13.85005
≥10 USD $11.3639
≥100 USD $11.00955
≥500 USD $10.65425
≥1000 USD $10.29895
Inventory: 8505
Minimum: 1
-
+
Technical Details
Technical
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number NCP5218
Pin Count 22
Number of Outputs 2
Qualification Status Not Qualified
Operating Supply Voltage 5V
Input Voltage-Nom 5V
Analog IC - Other Type SWITCHING CONTROLLER
Voltage - Input 4.5V~24V
Voltage - Output Adjustable
Control Mode VOLTAGE-MODE
Output Current-Max 3A
Control Technique PULSE WIDTH MODULATION
Switcher Configuration PUSH-PULL
Max Duty Cycle 90 %
Switching Frequency 460kHz
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position DUAL
Subcategory Switching Regulator or Controllers
Applications Controller, DDR
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 22
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2007
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Dimensions
Height Seated (Max) 1mm
Length 6mm
Width 5mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
Physical
Number of Pins 22
Package / Case 22-VFDFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 2 days ago)
