NCP51145PDR2G

ON Semiconductor
RoHS
RoHS RoHS compliant
Package 8-SOIC (0.154, 3.90mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Special Purpose
Description ON SEMICONDUCTOR NCP51145PDR2GLINEAR VOLT REG, DDR, 1.8A, SOIC-8
PDF
/
Buying Options
Total Price: USD $2.21
Unit Price: USD $2.21255
≥1 USD $2.21255
≥10 USD $1.81545
≥100 USD $1.75845
≥500 USD $1.70145
≥1000 USD $1.6454
Inventory: 1324
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Dimensions

Width 3.9mm
Length 4.9mm
Height 1.65mm

Technical

Reference Voltage 900mV
Max Input Voltage 5.5V
Min Input Voltage 1V
Quiescent Current 1mA
Output Current 1.8A
Voltage - Input 1V~5.5V
Polarity Positive
Operating Supply Voltage 5.25V
Max Output Current 1.8A
Output Type Adjustable
Output Voltage 6V
Number of Outputs 1
Applications LDO (Linear), DDR
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
Published 2005
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C

Physical

Weight 540.001716mg
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width) Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 4 Weeks
