NCP3218MNR2G
RoHS
/
Package 48-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Special Purpose
Description
Switching Controllers IMVP6.5 BUCK CONTROLLER
PDF
/
Buying Options
Total Price: USD $0.67
Unit Price: USD $0.665
≥1 USD $0.665
≥10 USD $0.5453
≥100 USD $0.52915
≥500 USD $0.51205
≥1000 USD $0.49495
Inventory: 124002
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status LAST SHIPMENTS (Last Updated: 22 hours ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 48-VFQFN Exposed Pad
Number of Pins 48
Weight 150.507618mg
Technical
Operating Temperature -40°C~100°C
Packaging Tape & Reel (TR)
Published 2010
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 48
ECCN Code EAR99
Terminal Finish Tin (Sn)
Applications Controller, Intel IMVP-6.5?
Subcategory Switching Regulator or Controllers
Terminal Position QUAD
Number of Functions 1
Terminal Pitch 0.4mm
Base Part Number NCP3218
Pin Count 48
Number of Outputs 1
Output Voltage 5V
Operating Supply Voltage 5.5V
Analog IC - Other Type SWITCHING CONTROLLER
Voltage - Input 3.3V~22V
Output Current 52A
Voltage - Output 0.013V~1.5V
Control Mode VOLTAGE-MODE
Halogen Free Halogen Free
Control Technique PULSE WIDTH MODULATION
Switcher Configuration PUSH-PULL
Switching Frequency 1MHz
Dimensions
Height Seated (Max) 0.8mm
Length 6mm
Width 6mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
