ADP3210MNR2G
RoHS
/
Package 40-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Special Purpose
Description
IC CTLR BUCK 7BIT MULTIPH 40QFN
PDF
/
Buying Options
Total Price: USD $1.43
Unit Price: USD $1.42975
≥1 USD $1.42975
≥10 USD $1.17325
≥100 USD $1.13715
≥500 USD $1.1001
≥1000 USD $1.06305
Inventory: 8005
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 6mm
Length 6mm
Technical
Switching Frequency-Max 280kHz
Switcher Configuration SINGLE
Control Technique PULSE WIDTH MODULATION
Halogen Free Halogen Free
Control Mode VOLTAGE-MODE
Voltage - Output 0.01V~1.5V
Voltage - Input 3.3V~22V
Analog IC - Other Type SWITCHING CONTROLLER
Input Voltage-Nom 5V
Operating Supply Voltage 5.5V
Number of Outputs 1
Pin Count 40
Base Part Number ADP3210
Terminal Pitch 0.5mm
Number of Functions 1
Terminal Position QUAD
Applications Controller, Power Supplies for Next-Generation Intel Processors
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 40
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature -10°C~100°C
Physical
Number of Pins 40
Package / Case 40-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 1 week ago)
