MAX8805ZEWEEE+
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Special Purpose
Description
Conv DC-DC Single-OUT Step Down 2.7V to 5.5V 16-Pin WLP
PDF
/
Inventory: 8549
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.295, 7.50mm Width)
Number of Pins 16
Technical
Operating Temperature -40°C~85°C
Packaging Tube
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Applications Converter, WCDMA PA Power
Subcategory Switching Regulator or Controllers
Technology BICMOS
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 225
Terminal Pitch 0.5mm
Base Part Number MAX8805
Number of Outputs 1
Max Output Current 650mA
Operating Supply Voltage 5.5V
Voltage - Input 2.7V~5.5V
Voltage - Output 0.4V~5.5V
Min Input Voltage 2.7V
Control Mode VOLTAGE-MODE
Max Input Voltage 5.5V
Switching Frequency 4MHz
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
