MAX8796GTJ+T
RoHS
RoHS compliant
RoHS compliantPackage 32-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Special Purpose
Description
Switching Controllers IMVP6 Single-Phase PWM Controller
PDF
/
Buying Options
Total Price: USD $2.49
Unit Price: USD $2.489
≥1 USD $2.489
≥10 USD $2.0425
≥100 USD $1.97885
≥500 USD $1.91425
≥1000 USD $1.8506
Inventory: 16118
Minimum: 1
-
+
Technical Details
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 32-WFQFN Exposed Pad
Number of Pins 32
Technical
Operating Temperature -40°C~105°C
Packaging Tape & Reel (TR)
Series Quick-PWM?
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 32
ECCN Code EAR99
Applications Controller, Intel IMVP-6, IMVP-6+
Subcategory Switching Regulator or Controllers
Technology BICMOS
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number MAX8796
Number of Outputs 1
Qualification Status Not Qualified
Operating Supply Voltage 26V
Input Voltage-Nom 5V
Analog IC - Other Type SWITCHING CONTROLLER
Voltage - Input 2V~26V
Control Mode CURRENT-MODE
Control Technique PULSE WIDTH MODULATION
Switcher Configuration BUCK
Switching Frequency 600kHz
Dimensions
Height Seated (Max) 0.8mm
Length 5mm
Width 5mm
Compliance
RoHS Status ROHS3 Compliant
