MAX8795AGCJ+
RoHS
RoHS compliant
RoHS compliantPackage 32-LQFP
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Special Purpose
Description
IC REG CONV TFT LCD 8OUT 32LQFP
PDF
/
Buying Options
Total Price: USD $4.49
Unit Price: USD $4.491429
≥1 USD $4.491429
≥10 USD $4.237196
≥100 USD $3.997353
≥500 USD $3.771083
≥1000 USD $3.557627
Inventory: 1121
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 7mm
Length 7mm
Height Seated (Max) 1.6mm
Technical
Switching Frequency-Max 1400kHz
Switcher Configuration BOOST
Control Technique PULSE WIDTH MODULATION
Max Input Voltage 5.5V
Control Mode CURRENT-MODE
Min Input Voltage 2.5V
Voltage - Output 2.5V~18V
Voltage - Input 2.5V~6V
Analog IC - Other Type SWITCHING REGULATOR
Input Voltage-Nom 3V
Operating Supply Voltage 5.5V
Max Output Current 500mA
Efficiency 85 %
Number of Outputs 8
Pin Count 32
Base Part Number MAX8795
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology BICMOS
Subcategory Switching Regulator or Controllers
Applications Converter, TFT LCD
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 32
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2012
Packaging Tray
Operating Temperature -40°C~105°C
Physical
Number of Pins 32
Package / Case 32-LQFP
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 17 Weeks
