MAX734CSA
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Special Purpose
Description
IC REG FLASH MEM 1OUT 8SOIC
PDF
/
Buying Options
Total Price: USD $3.93
Unit Price: USD $3.9292
≥1 USD $3.9292
≥10 USD $3.2243
≥100 USD $3.1236
≥500 USD $3.0229
≥1000 USD $2.9222
Inventory: 24795
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Technical
Switcher Configuration BOOST
Supply Current-Max (Isup) 2.5mA
Control Technique PULSE WIDTH MODULATION
Control Mode CURRENT-MODE
Voltage - Output 12V
Voltage - Input 3V~12V
Analog IC - Other Type SWITCHING REGULATOR
Input Voltage-Nom 5V
Output Voltage 12V
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-PDSO-G8
Pin Count 8
Base Part Number MAX734
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Number of Functions 1
Peak Reflow Temperature (Cel) 245
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Switching Regulator or Controllers
Applications Converter, Flash Memory
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Published 2003
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
