MAX606ESA+
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Special Purpose
Description
IC REG FLASH MEM 1OUT 8SOIC
PDF
/
Buying Options
Total Price: USD $8.1
Unit Price: USD $8.1048
≥1 USD $8.1048
≥10 USD $7.31896
≥100 USD $6.9784
≥500 USD $6.059328
≥1000 USD $5.786968
≥3000 USD $5.276357
Inventory: 94
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 1999
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Applications Converter, Flash Memory PCMCIA Cards
Subcategory Switching Regulator or Controllers
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number MAX606
Pin Count 8
JESD-30 Code R-PDSO-G8
Number of Outputs 1
Qualification Status Not Qualified
Output Voltage 12V
Input Voltage-Nom 3.3V
Analog IC - Other Type SWITCHING REGULATOR
Voltage - Input 3V~5.5V
Output Current 180mA
Voltage - Output 5V 12V 3V~12.5V
Control Mode CURRENT-MODE
Control Technique PULSE FREQUENCY MODULATION
Supply Current-Max (Isup) 0.5mA
Switcher Configuration BOOST
Dimensions
Length 4.9mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
