MAX5005ACUB+
RoHS
RoHS compliant
RoHS compliantPackage 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Special Purpose
Description
IC REG USB LDO 150MA 10-UMAX
PDF
/
Buying Options
Total Price: USD $7.36
Unit Price: USD $7.3568
≥1 USD $7.3568
≥10 USD $6.64928
≥100 USD $6.340224
≥500 USD $5.505104
≥1000 USD $5.445018
Inventory: 310
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Number of Pins 10
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Published 2002
JESD-609 Code e3
Pbfree Code yes
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 10
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Applications LDO (Linear), USB
Subcategory Other Regulators
Max Power Dissipation 444mW
Technology BICMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.5mm
Base Part Number MAX5005
Pin Count 10
Number of Outputs 1
Output Type Fixed
Max Output Current 150mA
Polarity Positive
Voltage - Input 4V~5.5V
Output Current 150mA
Accuracy 3 %
Voltage - Output 3.3V
Output Voltage 1 3.3V
Min Input Voltage 4V
Max Input Voltage 5.5V
Dropout Voltage 400mV
Dropout Voltage1-Nom 0.3V
Voltage Tolerance-Max 3%
Input Voltage Absolute-Max 6V
Input Bias Current 25μA
Dimensions
Length 3mm
Width 3mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
