MAX1880EUG+T
RoHS
RoHS compliant
RoHS compliantPackage 24-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Special Purpose
Description
IC REG CONV TFT LCD 4OUT 24TSSOP
PDF
/
Buying Options
Total Price: USD $3
Unit Price: USD $3.0008
≥1 USD $3.0008
Inventory: 30033
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 7.8mm
Height Seated (Max) 1.1mm
Technical
Switching Frequency-Max 1150kHz
Switcher Configuration BOOST
Supply Current-Max (Isup) 1mA
Control Technique PULSE WIDTH MODULATION
Output Current-Max 2.05A
Control Mode CURRENT-MODE
Voltage - Output 2.7V~13V
Voltage - Input 2.7V~5.5V
Analog IC - Other Type SWITCHING REGULATOR
Power Supplies 3/5V
Input Voltage-Nom 3V
Qualification Status Not Qualified
Number of Outputs 4
Pin Count 24
Base Part Number MAX1880
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Subcategory Power Management Circuits
Additional Feature ALSO CONTAINS CHARGE PUMP CONTROLLERS
Applications Converter, TFT LCD
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2015
Packaging Tape & Reel (TR)
Operating Temperature 0°C~85°C
Physical
Surface Mount YES
Package / Case 24-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
