MAX17582GTM+
RoHS
RoHS compliant
RoHS compliantPackage 48-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Special Purpose
Description
IC REG CTRL IMVP-6.5 1OUT 48TQFN
PDF
/
Buying Options
Total Price: USD $4.28
Unit Price: USD $4.278004
≥1 USD $4.278004
≥10 USD $4.035855
≥100 USD $3.807408
≥500 USD $3.591897
≥1000 USD $3.388581
Inventory: 1171
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 6mm
Length 6mm
Height Seated (Max) 0.8mm
Technical
Switching Frequency 800kHz
Switcher Configuration PHASE-SHIFT
Control Technique PULSE WIDTH MODULATION
Control Mode CURRENT-MODE
Voltage - Output 0.01V~1.5V
Voltage - Input 4.5V~5.5V
Operating Supply Current 5mA
Analog IC - Other Type DUAL SWITCHING CONTROLLER
Input Voltage-Nom 5V
Operating Supply Voltage 5.5V
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 48
Base Part Number MAX17582
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.4mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position QUAD
Technology BICMOS
Subcategory Switching Regulator or Controllers
Additional Feature ALSO HAS PFM CONTROL TECHNOQUE
Applications Controller, Intel IMVP-6.5?
ECCN Code EAR99
Number of Terminations 48
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Last Time Buy
Pbfree Code yes
Series Quick-PWM?
Published 2009
Packaging Tray
Operating Temperature -40°C~105°C
Physical
Number of Pins 48
Package / Case 48-WFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
