MAX17080GTL+
RoHS
RoHS compliant
RoHS compliantPackage 40-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Special Purpose
Description
IC REG CTRLR AMD SVI 3OUT 40TQFN
PDF
/
Buying Options
Total Price: USD $4.95
Unit Price: USD $4.9457
≥1 USD $4.9457
≥10 USD $4.0584
≥100 USD $3.93205
≥500 USD $3.80475
≥1000 USD $3.6784
Inventory: 5009
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 40-WFQFN Exposed Pad
Technical
Operating Temperature -40°C~105°C
Packaging Tube
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 40
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Applications Controller, AMD SVI
Additional Feature ALSO HAS PFM CONTROL TECHNIQUE
Subcategory Switching Regulator or Controllers
Technology BICMOS
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.4mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number MAX17080
Pin Count 40
JESD-30 Code S-XQCC-N40
Number of Outputs 3
Qualification Status Not Qualified
Input Voltage-Nom 12V
Analog IC - Other Type DUAL SWITCHING CONTROLLER
Voltage - Input 2.7V~5.5V
Voltage - Output 0.013V~1.55V
Control Mode CURRENT-MODE
Output Current-Max 4.5A
Control Technique PULSE WIDTH MODULATION
Switcher Configuration PUSH-PULL
Switching Frequency-Max 600kHz
Dimensions
Height Seated (Max) 0.8mm
Length 5mm
Width 5mm
Compliance
RoHS Status ROHS3 Compliant
