MAX1638EAG
RoHS
/
Package 24-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Special Purpose
Description
DC DC Cntrlr Single-OUT Step Down 4.5V to 5.5V Input 24-Pin SSOP
PDF
/
Inventory: 1630
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 24-SSOP (0.209, 5.30mm Width)
Number of Pins 24
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 1997
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 24
ECCN Code EAR99
Applications Controller, Intel Pentium? II
Subcategory Switching Regulator or Controllers
Technology BICMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Number of Functions 1
Terminal Pitch 0.65mm
Base Part Number MAX1638
Pin Count 24
Number of Outputs 1
Operating Supply Voltage 5.5V
Input Voltage-Nom 5V
Analog IC - Other Type SWITCHING CONTROLLER
Voltage - Input 4.5V~5.5V
Output Current 35A
Output Power 640mW
Voltage - Output 1.3V~3.5V
Control Mode CURRENT-MODE
Control Technique PULSE WIDTH MODULATION
Switcher Configuration PUSH-PULL
Dimensions
Length 8.2mm
Width 5.29mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
