TA78DL05AF
RoHS
/
Package /
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
THROUGH-HOLE Not Qualified BIPOLAR 8542.39.00.01 voltage regulator linear -40C 0.25A 2.3mm 0.6V
PDF
/
Buying Options
Total Price: USD $12.62
Unit Price: USD $12.6217
≥1 USD $12.6217
≥10 USD $10.3569
≥100 USD $10.03295
≥500 USD $9.709
≥1000 USD $9.386
Inventory: 2154
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Line Regulation-Max (%/V) 0.03%
Load Regulation-Max(%) 0.05%
Adjustability FIXED
Input Voltage Absolute-Max 29V
Operating Temperature TJ-Max 150°C
Dropout Voltage1-Max 0.6V
Output Current1-Max 0.25A
Voltage Tolerance-Max 5%
Regulator Type FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Dropout Voltage1-Nom 0.4V
Input Voltage (Max) 26V
Input Voltage (Min) 6V
Output Voltage 1 5V
Voltage - Output 5V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-PSIP-T3
Pin Count 3
Terminal Pitch 2.3mm
Number of Functions 1
Terminal Form THROUGH-HOLE
Terminal Position SINGLE
Technology BIPOLAR
Subcategory Other Regulators
HTS Code 8542.39.00.01
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 3
JESD-609 Code e0
Physical
Surface Mount NO
