TK11247BMCL
RoHS
/
Package /
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Lead Free GULL WING Not Qualified BIPOLAR voltage regulator linear 150C 0.15A 3.4mm 4.795V
PDF
/
Inventory: 9847
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 0.95mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 6
JESD-30 Code R-PDSO-G6
Number of Outputs 1
Qualification Status Not Qualified
Output Voltage 1 4.7V
Input Voltage (Min) 5.7V
Input Voltage (Max) 14.5V
Dropout Voltage1-Nom 0.26V
Output Voltage1-Max 4.795V
Output Voltage1-Min 4.605V
Technology BIPOLAR
Packing Method TAPE AND REEL
Subcategory Other Regulators
HTS Code 8542.39.00.01
ECCN Code EAR99
Number of Terminations 6
Pbfree Code no
Packaging Tape & Reel (TR)
Line Regulation-Max (%/V) 0.02%
Load Regulation-Max(%) 0.09%
Adjustability FIXED
Input Voltage Absolute-Max 16V
Operating Temperature TJ-Max 150°C
Dropout Voltage1-Max 0.39V
Output Current1-Max 0.15A
Voltage Tolerance-Max 2.02%
Regulator Type FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Physical
Surface Mount YES
Compliance
Lead Free Lead Free
RoHS Status Non-RoHS Compliant
Dimensions
Width 2.2mm
Length 3.4mm
Height Seated (Max) 1.4mm
