V62/06652-09XE

Texas Instruments
RoHS
/
Package SOT-23
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description Lead Free Positive GULL WING NMOS voltage regulator linear 125C 638mW 150mA 1.45mm
PDF
/
Inventory: 1859
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 1 week ago)

Physical

Package / Case SOT-23
Surface Mount YES
Number of Pins 5

Technical

JESD-609 Code e4
Pbfree Code yes
Moisture Sensitivity Level (MSL) 1
Number of Terminations 5
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Subcategory Other Regulators
Packing Method TR
Technology NMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Pin Count 5
Number of Outputs 1
Output Type Fixed
Max Output Current 150mA
Polarity Positive
Power Dissipation-Max 638mW
Current - Output 150mA
Quiescent Current 400μA
Accuracy 1 %
Max Output Voltage 1.25V
Voltage - Output 2.5V
Output Voltage 1 1.25V
Min Input Voltage 1.7V
Max Input Voltage 5.5V
Dropout Voltage 100mV
Dropout Voltage1-Nom 0.03V
Min Output Voltage 1.25V
Voltage Tolerance-Max 1%

Dimensions

Height 1.45mm
Length 2.9mm
Width 1.6mm
Thickness 1.2mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
