V62/03636-10XE
RoHS
/
Package HTSSOP EP
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Lead Free Positive GULL WING PMOS voltage regulator linear 125C 7.2W 1.5A 1.2mm
PDF
/
Inventory: 2375
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Package / Case HTSSOP EP
Surface Mount YES
Number of Pins 20
Technical
Packaging Tape and Reel
JESD-609 Code e4
Pbfree Code yes
Moisture Sensitivity Level (MSL) 2
Number of Terminations 20
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Subcategory Other Regulators
Packing Method TR
Technology PMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.65mm
Pin Count 20
Number of Outputs 1
Output Type Fixed
Max Output Current 1.5A
Polarity Positive
Power Dissipation-Max 7.2W
Power Dissipation 7.2W
Current - Output 1.5A
Max Input Voltage 5.5V
Dropout Voltage 160mV
Dropout Voltage1-Nom 0.16V
Min Output Voltage 3.3V
Voltage Tolerance-Max 2%
Output Voltage Accuracy 2 %
Line Regulation-Max (%/V) 0.0023%
Voltage Reference 1.1834V
Current - Input Bias 75μA
Min Input Voltage 2.7V
Output Voltage 1 3.3V
Voltage - Output 3.3V
Max Output Voltage 3.3V
Accuracy 2 %
Quiescent Current 70μA
Dimensions
Height 1.2mm
Length 6.5mm
Width 4.4mm
Thickness 1mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
