V62/03635-11XE
RoHS
/
Package /
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TR RoHS Compliant Nickel/Palladium/Gold (Ni/Pd/Au) ACTIVE (Last Updated: 10hours ago) voltage regulator linear 400mV 1.2mm 2A 125C
PDF
/
Inventory: 8107
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Thickness 1mm
Width 4.4mm
Length 6.5mm
Height 1.2mm
Technical
Voltage Reference 1.18V
Line Regulation-Max (%/V) 0.1
Min Output Voltage 1.5V
Dropout Voltage1-Nom 0.21V
Dropout Voltage 400mV
Max Input Voltage 5V
Current - Input Bias 75μA
Min Input Voltage 2.7V
Voltage - Output 5V
Max Output Voltage 5V
Accuracy 2 %
Quiescent Current 70μA
Current - Output 2A
Polarity Positive
Max Output Current 2A
Output Type Adjustable
Number of Outputs 1
Pin Count 20
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Packing Method TR
Subcategory Other Regulators
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 2
Pbfree Code yes
JESD-609 Code e4
Physical
Number of Pins 20
Surface Mount YES
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 10 hours ago)
