UC2834NG4 image
Favorite
UC2834NG4 image
Favorite
RoHS
/
Package N
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description Contains Lead THROUGH-HOLE BIPOLAR EAR99 voltage regulator linear 85C 1W 350mA 4.57mm
PDF
/
Inventory: 2734
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Package / Case N
Surface Mount NO
Number of Pins 16
Weight 1.05001g

Technical

JESD-609 Code e4
Pbfree Code yes
Number of Terminations 16
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Power Rating 1W
Technology BIPOLAR
Terminal Position DUAL
Terminal Form THROUGH-HOLE
Number of Functions 1
Supply Voltage 15V
Pin Count 16
Number of Outputs 2
Output Type Adjustable
Max Output Current 350mA
Supply Voltage-Min (Vsup) 5V
Number of Channels 1
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Operating Supply Current 5.5mA
Current - Output 350mA
Adjustable Threshold NO
Quiescent Current 5.5mA
Voltage - Output 1.5V
Min Input Voltage 5V
Max Input Voltage 35V

Dimensions

Height 4.57mm
Length 19.3mm
Width 6.35mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Contains Lead
