UC2832DWTRG4

Texas Instruments
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description Contains Lead GULL WING UNDER AND OVER-VOLTAGE FAULT ALERT WITH PROGRAMMABLE DELAY e4 voltage regulator linear 85C 400mA 2.65mm 40V
PDF
/
Inventory: 5609
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Package / Case SOIC
Surface Mount YES
Number of Pins 16
Weight 470.006744mg

Technical

Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Moisture Sensitivity Level (MSL) 2
Number of Terminations 16
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 85°C
Min Operating Temperature -25°C
Additional Feature UNDER AND OVER-VOLTAGE FAULT ALERT WITH PROGRAMMABLE DELAY
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 15V
Pin Count 16
Number of Outputs 1
Output Type Fixed
Max Output Current 400mA
Supply Voltage-Max (Vsup) 36V
Temperature Grade INDUSTRIAL
Analog IC - Other Type ANALOG CIRCUIT
Operating Supply Current 3.3mA
Current - Output 100mA
Quiescent Current 3.3mA
Voltage - Output 2V
Min Input Voltage 4.5V
Max Input Voltage 40V

Dimensions

Height Seated (Max) 2.65mm
Width 7.5mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Contains Lead
