UC282T-1
RoHS
RoHS compliant
RoHS compliantPackage TO-220-5
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Obsolete Lead Free Positive BIPOLAR Linear Voltage Regulator IC -40C~100C 3A 350mV
PDF
/
Buying Options
Total Price: USD $4.94
Unit Price: USD $4.93525
≥1 USD $4.93525
≥10 USD $4.04985
≥100 USD $3.92255
≥500 USD $3.7962
≥1000 USD $3.66985
Inventory: 6002
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Min Output Voltage 1.5V
Dropout Voltage1-Nom 0.35V
Dropout Voltage 350mV
Reference Voltage 1.2V
Voltage Dropout (Max) 2.2V @ 3A
Protection Features Over Temperature, Reverse Polarity, Short Circuit
Min Input Voltage 1.85V
Number of Regulators 1
Output Voltage 1 1.5V
Quiescent Current 30mA
Output Configuration Positive
Max Output Current 3A
Output Type Fixed
Output Voltage 1.5V
Voltage - Input (Max) 7.5V
Number of Outputs 1
Pin Count 3
Base Part Number UC282
Number of Functions 1
Terminal Position SINGLE
Technology BIPOLAR
Subcategory Other Regulators
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
JESD-609 Code e3
Packaging Tube
Operating Temperature -40°C~100°C
Physical
Number of Pins 5
Package / Case TO-220-5
Mounting Type Through Hole
Mount Through Hole
