UA79M06CKTPR
RoHS
/
Package /
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
GULL WING Not Qualified BIPOLAR 8542.39.00.01 voltage regulator linear 125C 0.5A 6.145mm 2.3V
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.2552
≥1 USD $0.2552
Inventory: 3026
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 6.04mm
Length 6.145mm
Height Seated (Max) 2.16mm
Technical
Line Regulation-Max (%/V) 0.06%
Load Regulation-Max(%) 0.12%
Adjustability FIXED
Input Voltage Absolute-Max 35V
Operating Temperature TJ-Max 125°C
Output Current1-Max 0.5A
Voltage Tolerance-Max 5%
Regulator Type FIXED NEGATIVE SINGLE OUTPUT STANDARD REGULATOR
Dropout Voltage1-Nom 2.3V
Input Voltage (Max) 25V
Input Voltage (Min) 8V
Output Voltage 1 6V
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-PSSO-G2
Pin Count 2
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.29mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position SINGLE
Technology BIPOLAR
Packing Method TAPE AND REEL
Subcategory Other Regulators
HTS Code 8542.39.00.01
ECCN Code EAR99
Number of Terminations 2
Physical
Surface Mount YES
