UA78M05CDCYG3
RoHS
RoHS compliant
RoHS compliantPackage TO-261-4, TO-261AA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
UA78M05 Tube Surface Mount Over Current Over Temperature Short Circuit voltage regulator linear 2V 1.8mm 500mA 0C~125C
PDF
/
Buying Options
Total Price: USD $0.8
Unit Price: USD $0.8008
≥1 USD $0.8008
≥10 USD $0.704
≥100 USD $0.53966
≥500 USD $0.501274
≥1000 USD $0.426624
≥3000 USD $0.341299
Inventory: 1130
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-261-4, TO-261AA
Number of Pins 4
Technical
Operating Temperature 0°C~125°C
Packaging Tube
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 4
ECCN Code EAR99
Subcategory Other Regulators
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 2.3mm
Base Part Number UA78M05
Pin Count 4
Number of Outputs 1
Voltage - Input (Max) 25V
Output Voltage 5V
Output Type Fixed
Max Output Current 500mA
Output Configuration Positive
Quiescent Current 4.5mA
Output Voltage 1 5V
Number of Regulators 1
Min Input Voltage 7V
Protection Features Over Current, Over Temperature, Short Circuit
Voltage Dropout (Max) 2V @ 350mA
PSRR 80dB (120Hz)
Dropout Voltage 2V
Dropout Voltage1-Nom 2V
Power Supply Rejection Ratio (PSRR) 80dB
Voltage Tolerance-Max 5%
Nominal Output Voltage 5V
Dimensions
Height 1.8mm
Length 6.5mm
Width 3.5mm
Thickness 1.6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
