TPS7A8801QRTJRQ1
RoHS
RoHS compliant
RoHS compliantPackage 20-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TPS7A8801 Tape & Reel (TR) Surface Mount Over Current Over Temperature Under Voltage Lockout (UVLO) voltage regulator linear 0.13V 800mum 1A -40C~140C TJ
PDF
/
Buying Options
Total Price: USD $47
Unit Price: USD $47.0041
≥1 USD $47.0041
≥10 USD $38.5681
≥100 USD $37.36255
≥500 USD $36.157
≥1000 USD $34.9524
Inventory: 1856
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mounting Type Surface Mount
Package / Case 20-WFQFN Exposed Pad
Surface Mount YES
Number of Pins 20
Technical
Operating Temperature -40°C~140°C TJ
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q100
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 20
ECCN Code EAR99
Terminal Finish TIN
Packing Method TR
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number TPS7A8801
Current - Supply (Max) 4mA
Number of Outputs 2
Voltage - Input (Max) 6.5V
Output Type Adjustable
Output Configuration Positive
Current - Output 1A
Control Features Enable, Power Good, Soft Start
Input Voltage (Min) 1.4V
Voltage - Output (Min/Fixed) 0.8V
Number of Regulators 2
Protection Features Over Current, Over Temperature, Under Voltage Lockout (UVLO)
Current - Quiescent (Iq) 3.5mA
Voltage Dropout (Max) 0.225V @ 1A
PSRR 40dB (500kHz)
Dropout Voltage1-Nom 0.13V
Output Voltage1-Min 0.8V
Voltage - Output (Max) 5.15V
Output Voltage2-Min 0.785V
Dimensions
Height 800μm
Length 4mm
Width 4mm
Thickness 730μm
Compliance
RoHS Status ROHS3 Compliant
