TPS7A8300ARGRT
RoHS
RoHS compliant
RoHS compliantPackage 20-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TPS7A8300 Tape & Reel (TR) Surface Mount Over Current Over Temperature Under Voltage Lockout (UVLO) voltage regulator linear 0.075V 1mm 2A -40C~125C TJ
PDF
/
Buying Options
Total Price: USD $4.63
Unit Price: USD $4.6288
≥1 USD $4.6288
≥10 USD $4.16064
≥100 USD $3.9336
≥500 USD $3.40912
Inventory: 960
Minimum: 1
-
+
Technical Details
Technical
Number of Terminations 20
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Packing Method TR
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number TPS7A8300
Current - Supply (Max) 5mA
Number of Outputs 1
Voltage - Input (Max) 6.5V
Output Type Adjustable/Programmable
Output Configuration Positive
Current - Output 2A
Control Features Enable, Power Good, Soft Start
Voltage - Output (Min/Fixed) 0.8V
Number of Regulators 1
Protection Features Over Current, Over Temperature, Under Voltage Lockout (UVLO)
Current - Quiescent (Iq) 4mA
Voltage Dropout (Max) 0.3V @ 2A
PSRR 42dB ~ 25dB (10kHz ~ 500kHz)
Dropout Voltage1-Nom 0.075V
Output Voltage1-Min 0.8V
Voltage - Output (Max) 5.2V
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ
Dimensions
Height 1mm
Length 3.5mm
Width 3.5mm
Thickness 900μm
Compliance
RoHS Status ROHS3 Compliant
Physical
Number of Pins 20
Surface Mount YES
Package / Case 20-VFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
