TPS7A7100RGWT
RoHS
RoHS compliant
RoHS compliantPackage 20-VQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
FIXED/ADJUSTABLE TPS7A7100 Cut Tape (CT) Surface Mount voltage regulator linear 140mV 1mm 1A -40C~125C
PDF
/
Buying Options
Total Price: USD $3.08
Unit Price: USD $3.08
≥1 USD $3.08
≥10 USD $2.76496
≥100 USD $2.6136
≥500 USD $2.265208
Inventory: 3160
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 900μm
Width 5mm
Length 5mm
Height 1mm
Technical
Adjustability FIXED/ADJUSTABLE
Output Voltage Accuracy 2 %
Min Current Limit 1.1A
Voltage Tolerance-Max 3%
Min Output Voltage 900mV
Dropout Voltage1-Nom 0.14V
Dropout Voltage 140mV
Reference Voltage 500mV
Voltage Dropout (Max) 0.35V @ 1A
Current - Quiescent (Iq) 4mA
Protection Features Over Current, Over Temperature, Under Voltage Lockout (UVLO)
Min Input Voltage 1.5V
Number of Regulators 1
Voltage - Output (Min/Fixed) 0.9V
Max Output Voltage 5V
Accuracy 2 %
Control Features Enable, Power Good, Soft Start
Quiescent Current 10μA
Output Configuration Positive
Max Output Current 1A
Output Type Adjustable (Fixed)
Output Voltage 5V
Voltage - Input (Max) 6.5V
Number of Outputs 1
Pin Count 20
Base Part Number TPS7A7100
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Technology CMOS
Packing Method TR
Subcategory Other Regulators
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Cut Tape (CT)
Operating Temperature -40°C~125°C
Physical
Number of Pins 20
Surface Mount YES
Package / Case 20-VQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
Alternative Model
