TPS7A4901DRBR
RoHS
RoHS compliant
RoHS compliantPackage 8-VDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TPS7A4901 Tape & Reel (TR) Surface Mount Over Current Over Temperature Under Voltage Lockout (UVLO) voltage regulator linear 333mV 1mm 150mA -40C~125C
PDF
/
Buying Options
Total Price: USD $1.78
Unit Price: USD $1.78009
≥1 USD $1.78009
≥10 USD $1.67933
≥100 USD $1.58428
≥500 USD $1.4946
≥1000 USD $1.41
≥3000 USD $1.33019
Inventory: 6853
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 880μm
Width 3mm
Length 3mm
Height 1mm
Technical
Max Junction Temperature (Tj) 125°C
Min Current Limit 220mA
Dropout Voltage1-Nom 0.26V
Dropout Voltage 333mV
PSRR 72dB (120Hz)
Voltage Dropout (Max) 0.6V @ 150mA
Current - Quiescent (Iq) 100μA
Protection Features Over Current, Over Temperature, Under Voltage Lockout (UVLO)
Min Input Voltage 3V
Number of Regulators 1
Voltage - Output (Min/Fixed) 1.194V
Accuracy 1.5 %
Control Features Enable
Quiescent Current 100μA
Output Configuration Positive
Min Supply Voltage 3V
Max Supply Voltage 35V
Max Output Current 150mA
Output Type Adjustable
Output Voltage 33V
Voltage - Input (Max) 35V
Number of Outputs 1
Current - Supply (Max) 800μA
Base Part Number TPS7A4901
Terminal Pitch 0.65mm
Number of Functions 1
Terminal Form NO LEAD
Terminal Position DUAL
Technology BIPOLAR
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Package / Case 8-VDFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
