TPS7A4901DGNT
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TPS7A4901 Tape & Reel (TR) Surface Mount Over Current Over Temperature Under Voltage Lockout (UVLO) voltage regulator linear 260mV 1.1mm 150mA 1.83W
PDF
/
Buying Options
Total Price: USD $3.01
Unit Price: USD $3.0096
≥1 USD $3.0096
≥10 USD $2.70336
≥100 USD $2.555872
≥500 USD $2.21496
Inventory: 4394
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Mounting Type Surface Mount
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width) Exposed Pad
Surface Mount YES
Number of Pins 8
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Other Regulators
Packing Method TR
Max Power Dissipation 1.83W
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.65mm
Base Part Number TPS7A4901
Pin Count 8
Current - Supply (Max) 800μA
Number of Outputs 1
Voltage - Input (Max) 35V
Output Voltage 33V
Output Type Adjustable
Max Output Current 150mA
Output Configuration Positive
Power Dissipation 1.83W
Quiescent Current 60μA
Control Features Enable
Accuracy 1.5 %
Max Output Voltage 33V
Voltage - Output (Min/Fixed) 1.194V
Min Input Voltage 3V
Protection Features Over Current, Over Temperature, Under Voltage Lockout (UVLO)
Current - Quiescent (Iq) 100μA
Voltage Dropout (Max) 0.6V @ 150mA
PSRR 72dB (120Hz)
Reference Voltage 1.212V
Dropout Voltage 260mV
Dropout Voltage1-Nom 0.26V
Min Output Voltage 1.2V
Voltage - Output (Max) 33V
Min Current Limit 220mA
Output Voltage Accuracy 1.5 %
Dimensions
Height 1.1mm
Length 3mm
Width 3mm
Thickness 1.02mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
