TPS7A1030PDSET
RoHS
RoHS compliant
RoHS compliantPackage 6-WFDFN
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TPS7A1030 Cut Tape (CT) Surface Mount Over Current Over Temperature UVLO voltage regulator linear 3.045V 0.8mm 300mA -40C~125C TJ
PDF
/
Buying Options
Total Price: USD $1.05
Unit Price: USD $1.0472
≥1 USD $1.0472
≥10 USD $0.93368
≥100 USD $0.885984
≥500 USD $0.72776
Inventory: 788
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case 6-WFDFN
Surface Mount YES
Technical
Operating Temperature -40°C~125°C TJ
Packaging Cut Tape (CT)
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Terminal Position DUAL
Terminal Form NO LEAD
Number of Functions 1
Terminal Pitch 0.5mm
Reach Compliance Code compliant
Base Part Number TPS7A1030
JESD-30 Code S-PDSO-N6
Current - Supply (Max) 9μA
Number of Outputs 1
Voltage - Input (Max) 3.3V
Output Type Fixed
Output Configuration Positive
Current - Output 300mA
Control Features Enable
Output Voltage 1 3V
Voltage - Output (Min/Fixed) 3V
Number of Regulators 1
Protection Features Over Current, Over Temperature, UVLO
Current - Quiescent (Iq) 2.6μA
Voltage Dropout (Max) 0.09V @ 300mA
PSRR 60dB ~ 35dB (1kHz ~ 1.5MHz)
Dropout Voltage1-Nom 0.07V
Output Voltage1-Max 3.045V
Output Voltage1-Min 2.955V
Dimensions
Height Seated (Max) 0.8mm
Compliance
RoHS Status RoHS Compliant
