TPS7A0527PDBZT
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Active Positive GULL WING R-PDSO-G3 Linear Voltage Regulator IC -40C~125C TJ 200mA 2.92mm 2.754V
PDF
/
Buying Options
Total Price: USD $1.14
Unit Price: USD $1.144
≥1 USD $1.144
≥10 USD $1.0252
≥100 USD $0.972928
≥500 USD $0.799304
Inventory: 187
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Surface Mount YES
Technical
Operating Temperature -40°C~125°C TJ
Packaging Tape & Reel (TR)
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish Matte Tin (Sn)
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.95mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 7A0527
JESD-30 Code R-PDSO-G3
Number of Outputs 1
Voltage - Input (Max) 5.5V
Output Type Fixed
Output Configuration Positive
Current - Output 200mA
Control Features Enable
Output Voltage 1 2.7V
Input Voltage (Min) 3.2V
Voltage - Output (Min/Fixed) 2.7V
Number of Regulators 1
Protection Features Over Current, Over Temperature, Under Voltage Lockout (UVLO)
Current - Quiescent (Iq) 3μA
Voltage Dropout (Max) 0.308V @ 200mA
PSRR 40dB (1kHz ~ 1MHz)
Dropout Voltage1-Nom 0.204V
Output Voltage1-Max 2.754V
Output Voltage1-Min 2.646V
Dimensions
Length 2.92mm
Compliance
RoHS Status ROHS3 Compliant
