TPS7A0510PDBVR
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
7A0510 Tape & Reel (TR) Surface Mount Over Current Over Temperature Under Voltage Lockout (UVLO) voltage regulator linear 0.204V 2.9mm 200mA -40C~125C TJ
PDF
/
Buying Options
Total Price: USD $0.39
Unit Price: USD $0.3872
≥1 USD $0.3872
≥10 USD $0.33
≥100 USD $0.308
≥500 USD $0.2464
≥1000 USD $0.228765
≥3000 USD $0.193582
Inventory: 1207
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case SC-74A, SOT-753
Surface Mount YES
Technical
Operating Temperature -40°C~125°C TJ
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.95mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 7A0510
JESD-30 Code R-PDSO-G5
Number of Outputs 1
Voltage - Input (Max) 5.5V
Output Type Fixed
Output Configuration Positive
Current - Output 200mA
Control Features Enable
Output Voltage 1 1V
Voltage - Output (Min/Fixed) 1V
Number of Regulators 1
Protection Features Over Current, Over Temperature, Under Voltage Lockout (UVLO)
Current - Quiescent (Iq) 3μA
Voltage Dropout (Max) 0.837V @ 200mA
PSRR 40dB (1kHz ~ 1MHz)
Dropout Voltage1-Nom 0.204V
Output Voltage1-Min 0.97V
Dimensions
Length 2.9mm
Compliance
RoHS Status ROHS3 Compliant
Alternative Model
