TPS799L54YZYR
RoHS
RoHS compliant
RoHS compliantPackage 5-XFBGA, DSBGA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TPS799L54 Tape & Reel (TR) Surface Mount Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO) voltage regulator linear 90mV 500mum 200mA -40C~125C
PDF
/
Buying Options
Total Price: USD $1.29
Unit Price: USD $1.28915
≥1 USD $1.28915
≥10 USD $1.0583
≥100 USD $1.02505
≥500 USD $0.9918
≥1000 USD $0.95855
Inventory: 19723
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 280μm
Width 0m
Length 0m
Height 500μm
Technical
Input Voltage Absolute-Max 7V
Min Current Limit 220mA
Voltage Tolerance-Max 2%
Dropout Voltage1-Nom 0.09V
Dropout Voltage 90mV
PSRR 70dB ~ 38dB (100Hz ~ 100kHz)
Voltage Dropout (Max) 0.16V @ 200mA
Current - Quiescent (Iq) 60μA
Protection Features Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Min Input Voltage 2.7V
Number of Regulators 1
Output Voltage 1 5.4V
Accuracy 1 %
Control Features Enable
Quiescent Current 40μA
Output Configuration Positive
Max Output Current 200mA
Output Type Fixed
Output Voltage 5.4V
Voltage - Input (Max) 6.5V
Number of Outputs 1
Base Part Number TPS799L54
Number of Functions 1
Terminal Form BALL
Terminal Position BOTTOM
Technology BICMOS
Packing Method TR
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 5
Package / Case 5-XFBGA, DSBGA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 16 Weeks
