TPS79933DDCT
RoHS
RoHS compliant
RoHS compliantPackage SOT-23-5 Thin, TSOT-23-5
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TPS79933 Tape & Reel (TR) Surface Mount Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO) voltage regulator linear 90mV 1.1mm 200mA 500mW
PDF
/
Buying Options
Total Price: USD $1.05
Unit Price: USD $1.0472
≥1 USD $1.0472
≥10 USD $0.93896
≥100 USD $0.890912
≥500 USD $0.731808
Inventory: 1117
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 870μm
Width 1.6mm
Length 2.9mm
Height 1.1mm
Technical
Output Voltage Accuracy 1 %
Input Bias Current 40μA
Nominal Output Voltage 3.3V
Min Current Limit 220mA
Voltage Tolerance-Max 2%
Min Output Voltage 3.3V
Dropout Voltage1-Nom 0.1V
Dropout Voltage 90mV
PSRR 70dB ~ 38dB (100Hz ~ 100kHz)
Voltage Dropout (Max) 0.16V @ 200mA
Current - Quiescent (Iq) 60μA
Protection Features Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Min Input Voltage 2.7V
Number of Regulators 1
Output Voltage 1 3.3V
Max Output Voltage 3.3V
Accuracy 2 %
Control Features Enable
Quiescent Current 40μA
Power Dissipation 500mW
Output Configuration Positive
Min Supply Voltage 2.7V
Max Supply Voltage 6.5V
Max Output Current 200mA
Output Type Fixed
Output Voltage 3.3V
Number of Outputs 1
Pin Count 5
Base Part Number TPS79933
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Max Power Dissipation 500mW
Packing Method TR
Subcategory Other Regulators
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 5
Surface Mount YES
Package / Case SOT-23-5 Thin, TSOT-23-5
Mounting Type Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 6 Weeks
