TPS799285DRVTG4

Texas Instruments
RoHS
/
Package /
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description Tape and Reel RoHS Compliant Nickel/Palladium/Gold (Ni/Pd/Au) DUAL voltage regulator linear 100mV 2mm 200mA 1.54W
PDF
/
Buying Options
Total Price: USD $1.5
Unit Price: USD $1.500312
≥1 USD $1.500312
≥10 USD $1.415382
≥100 USD $1.335276
≥500 USD $1.259684
≥1000 USD $1.188378
Inventory: 1641
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Width 2mm
Length 2mm
Height Seated (Max) 0.8mm

Technical

Output Voltage Accuracy 1 %
Min Current Limit 200mA
Voltage Tolerance-Max 2%
Min Output Voltage 2.85V
Dropout Voltage1-Nom 0.1V
Dropout Voltage 100mV
Max Input Voltage 6.5V
Min Input Voltage 2.7V
Output Voltage 1 2.85V
Voltage - Output 2.85V
Max Output Voltage 2.85V
Accuracy 2 %
Quiescent Current 40μA
Current - Output 200mA
Power Dissipation 1.54W
Power Dissipation-Max 1.54W
Polarity Positive
Max Output Current 200mA
Output Type Fixed
Number of Outputs 1
Pin Count 6
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Technology BICMOS
Subcategory Other Regulators
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1
Pbfree Code yes
JESD-609 Code e4
Packaging Tape and Reel

Physical

Number of Pins 6
Surface Mount YES
