TPS79925QDDCRQ1
RoHS
RoHS compliant
RoHS compliantPackage SOT-23-5 Thin, TSOT-23-5
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TPS79925 Tape & Reel (TR) Surface Mount Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO) voltage regulator linear 0.1V 1.1mm 200mA 500mW
PDF
/
Buying Options
Total Price: USD $6.01
Unit Price: USD $6.01445
≥1 USD $6.01445
≥10 USD $4.93525
≥100 USD $4.7804
≥500 USD $4.6265
≥1000 USD $4.4726
Inventory: 9007
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 870μm
Width 1.6mm
Length 2.9mm
Height 1.1mm
Technical
Output Voltage Accuracy 1 %
Min Current Limit 200mA
Voltage Tolerance-Max 2%
Min Output Voltage 2.5V
Dropout Voltage1-Nom 0.1V
PSRR 70dB ~ 38dB (100Hz ~ 100kHz)
Voltage Dropout (Max) 0.18V @ 200mA
Current - Quiescent (Iq) 60μA
Protection Features Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Min Input Voltage 2.7V
Number of Regulators 1
Output Voltage 1 2.5V
Max Output Voltage 2.5V
Accuracy 2 %
Control Features Enable
Quiescent Current 40μA
Power Dissipation 500mW
Output Configuration Positive
Max Output Current 200mA
Output Type Fixed
Output Voltage 2.5V
Voltage - Input (Max) 6.5V
Number of Outputs 1
Pin Count 5
Base Part Number TPS79925
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Max Power Dissipation 500mW
Packing Method TR
Subcategory Other Regulators
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series Automotive, AEC-Q100
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 5
Surface Mount YES
Package / Case SOT-23-5 Thin, TSOT-23-5
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
