TPS79613DRBT
RoHS
RoHS compliant
RoHS compliantPackage 8-VDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Obsolete Lead Free Positive BICMOS Linear Voltage Regulator IC -40C~125C 1A 3mm 200mV
PDF
/
Buying Options
Total Price: USD $1.86
Unit Price: USD $1.860763
≥1 USD $1.860763
≥10 USD $1.755435
≥100 USD $1.656072
≥500 USD $1.562329
≥1000 USD $1.473896
Inventory: 1500
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3mm
Length 3mm
Technical
Input Bias Current 265μA
Min Current Limit 2.4A
Voltage Tolerance-Max 2%
Min Output Voltage 1.3V
Dropout Voltage 200mV
PSRR 59dB ~ 42dB (100Hz ~ 100kHz)
Current - Quiescent (Iq) 385μA
Protection Features Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Min Input Voltage 2.7V
Number of Regulators 1
Output Voltage 1 1.3V
Max Output Voltage 1.3V
Accuracy 2 %
Control Features Enable
Quiescent Current 260μA
Output Configuration Positive
Max Output Current 1A
Output Type Fixed
Output Voltage 1.3V
Voltage - Input (Max) 5.5V
Number of Outputs 1
Pin Count 8
Base Part Number TPS79613
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Technology BICMOS
Packing Method TAPE AND REEL
Subcategory Other Regulators
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-VDFN Exposed Pad
Mounting Type Surface Mount
