TPS79501DRBRG4
RoHS
RoHS compliant
RoHS compliantPackage 8-VDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Active Lead Free Positive Gold Linear Voltage Regulator IC -40C~125C 500mA 1mm 105mV
PDF
/
Buying Options
Total Price: USD $8.05
Unit Price: USD $8.0465
≥1 USD $8.0465
≥10 USD $6.6025
≥100 USD $6.39635
≥500 USD $6.18925
≥1000 USD $5.9831
Inventory: 1789
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Thickness 880μm
Width 3mm
Length 3mm
Height 1mm
Technical
Output Voltage Accuracy 3 %
Input Bias Current 265μA
Nominal Output Voltage 5.5V
Min Current Limit 2.4A
Min Output Voltage 1.2V
Dropout Voltage1-Nom 0.11V
Dropout Voltage 105mV
Reference Voltage 1.225V
PSRR 59dB ~ 39dB (100Hz ~ 100kHz)
Current - Quiescent (Iq) 385μA
Protection Features Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Min Input Voltage 2.7V
Number of Regulators 1
Max Output Voltage 5.5V
Accuracy 2 %
Control Features Enable
Quiescent Current 260μA
Output Configuration Positive
Max Output Current 500mA
Output Type Adjustable
Output Voltage 5.5V
Number of Outputs 1
Pin Count 8
Base Part Number TPS79501
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Technology BICMOS
Packing Method TR
Subcategory Other Regulators
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-VDFN Exposed Pad
Mounting Type Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
