TPS79030DBVT
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TPS79030 Tape & Reel (TR) Surface Mount Over Current Over Temperature Reverse Polarity voltage regulator linear 57mV 1.45mm 50mA 555mW
PDF
/
Buying Options
Total Price: USD $1.65
Unit Price: USD $1.6544
≥1 USD $1.6544
≥10 USD $1.48632
≥100 USD $1.402016
≥500 USD $1.1946
Inventory: 122
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mounting Type Surface Mount
Package / Case SC-74A, SOT-753
Surface Mount YES
Number of Pins 5
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Other Regulators
Power Rating 555mW
Packing Method TR
Max Power Dissipation 555mW
Technology PMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Base Part Number TPS79030
Pin Count 5
Number of Outputs 1
Voltage - Input (Max) 10V
Output Voltage 3V
Output Type Fixed
Max Output Current 50mA
Output Configuration Positive
Power Dissipation 555mW
Quiescent Current 20μA
Control Features Enable
Max Output Voltage 3V
Output Voltage 1 3V
Number of Regulators 1
Min Input Voltage 2.7V
Protection Features Over Current, Over Temperature, Reverse Polarity
Current - Quiescent (Iq) 28μA
Voltage Dropout (Max) 0.12V @ 50mA
PSRR 85dB (1kHz)
Dropout Voltage 57mV
Dropout Voltage1-Nom 0.057V
Min Output Voltage 3V
Voltage Tolerance-Max 3%
Nominal Output Voltage 3V
Input Bias Current 17μA
Dimensions
Height 1.45mm
Length 2.9mm
Width 1.6mm
Thickness 1.2mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
