TPS79025DBVT
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TPS79025 Tape & Reel (TR) Surface Mount Over Current Over Temperature Reverse Polarity voltage regulator linear 57mV 1.45mm 50mA 555mW
PDF
/
Buying Options
Total Price: USD $1.65
Unit Price: USD $1.6544
≥1 USD $1.6544
≥10 USD $1.48632
≥100 USD $1.402016
≥500 USD $1.1946
Inventory: 89
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.2mm
Width 1.6mm
Length 2.9mm
Height 1.45mm
Technical
Input Bias Current 17μA
Voltage Tolerance-Max 3%
Min Output Voltage 2.5V
Dropout Voltage1-Nom 0.057V
Dropout Voltage 57mV
PSRR 85dB (1kHz)
Current - Quiescent (Iq) 28μA
Protection Features Over Current, Over Temperature, Reverse Polarity
Min Input Voltage 2.7V
Number of Regulators 1
Output Voltage 1 2.5V
Max Output Voltage 2.5V
Control Features Enable
Quiescent Current 20μA
Power Dissipation 555mW
Output Configuration Positive
Max Output Current 50mA
Output Type Fixed
Output Voltage 2.5V
Voltage - Input (Max) 10V
Number of Outputs 1
Pin Count 5
Base Part Number TPS79025
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology PMOS
Max Power Dissipation 555mW
Packing Method TR
Subcategory Other Regulators
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 5
Surface Mount YES
Package / Case SC-74A, SOT-753
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 6 Weeks
