TPS78915DBVTG4

Texas Instruments
RoHS
/
Package SOT-23
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description Tape & Reel RoHS Compliant Nickel/Palladium/Gold (Ni/Pd/Au) DUAL voltage regulator linear 115mV 2.9mm 100mA 555mW
PDF
/
Buying Options
Total Price: USD $1.13
Unit Price: USD $1.128454
≥1 USD $1.128454
≥10 USD $1.064583
≥100 USD $1.004316
≥500 USD $0.947473
≥1000 USD $0.893842
Inventory: 4380
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Length 2.9mm

Technical

Voltage Tolerance-Max 3%
Min Output Voltage 1.5V
Dropout Voltage 115mV
Max Input Voltage 10V
Current - Input Bias 17μA
Min Input Voltage 2.7V
Output Voltage 1 1.5V
Voltage - Output 1.5V
Max Output Voltage 1.5V
Quiescent Current 20μA
Current - Output 100mA
Power Dissipation-Max 555mW
Polarity Positive
Max Output Current 100mA
Output Type Fixed
Number of Outputs 1
Pin Count 5
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology PMOS
Packing Method TAPE AND REEL
Subcategory Other Regulators
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1
JESD-609 Code e4
Packaging Tape & Reel

Physical

Number of Pins 5
Surface Mount YES
Package / Case SOT-23
