TPS78825DBVT
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TPS78825 Tape & Reel (TR) Surface Mount Over Current Over Temperature Reverse Polarity voltage regulator linear 150mV 1.45mm 100mA 555mW
PDF
/
Buying Options
Total Price: USD $1.44
Unit Price: USD $1.4432
≥1 USD $1.4432
≥10 USD $1.29976
≥100 USD $1.226368
≥500 USD $1.045
Inventory: 577
Minimum: 1
-
+
Technical Details
Technical
Subcategory Other Regulators
Power Rating 555mW
Packing Method TR
Max Power Dissipation 555mW
Technology PMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Base Part Number TPS78825
Pin Count 5
Number of Outputs 1
Voltage - Input (Max) 10V
Output Voltage 2.5V
Output Type Fixed
Max Output Current 100mA
Output Configuration Positive
Power Dissipation 555mW
Current - Output 150mA
Quiescent Current 20μA
Control Features Enable
Accuracy 3 %
Max Output Voltage 2.5V
Output Voltage 1 2.5V
Number of Regulators 1
Min Input Voltage 2.7V
Protection Features Over Current, Over Temperature, Reverse Polarity
Current - Quiescent (Iq) 385μA
Voltage Dropout (Max) 0.3V @ 150mA
PSRR 70dB (1kHz)
Dropout Voltage 150mV
Dropout Voltage1-Nom 0.15V
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Min Output Voltage 2.5V
Voltage Tolerance-Max 3%
Input Bias Current 17μA
Output Voltage Accuracy 3 %
Physical
Number of Pins 5
Surface Mount YES
Package / Case SC-74A, SOT-753
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 12 Weeks
Dimensions
Height 1.45mm
Length 2.9mm
Width 1.6mm
Thickness 1.2mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
