TPS780300250DRVT
RoHS
RoHS compliant
RoHS compliantPackage 6-WDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TPS780300250 Tape & Reel (TR) Surface Mount Over Current Over Temperature Reverse Polarity voltage regulator linear 200mV 800mum 150mA 1.54W
PDF
/
Buying Options
Total Price: USD $1.22
Unit Price: USD $1.2232
≥1 USD $1.2232
≥10 USD $1.09296
≥100 USD $1.037696
≥500 USD $0.852456
Inventory: 478
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Mounting Type Surface Mount
Package / Case 6-WDFN Exposed Pad
Surface Mount YES
Number of Pins 6
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Other Regulators
Power Rating 1.54W
Packing Method TR
Max Power Dissipation 1.54W
Technology PMOS
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Base Part Number TPS780300250
Pin Count 6
Current - Supply (Max) 5μA
Number of Outputs 1
Voltage - Input (Max) 5.5V
Output Voltage 5.25V
Output Type Fixed
Max Output Current 150mA
Output Configuration Positive
Power Dissipation 1.54W
Quiescent Current 500nA
Control Features Enable
Accuracy 3 %
Output Voltage 1 3V
Voltage - Output (Min/Fixed) 3V 2.5V
Number of Regulators 1
Min Input Voltage 2.2V
Protection Features Over Current, Over Temperature, Reverse Polarity
Current - Quiescent (Iq) 800nA
Voltage Dropout (Max) 0.25V @ 250mA 0.25V @ 250mA
PSRR 40dB ~ 15dB (10Hz ~ 1kHz)
Dropout Voltage 200mV
Dropout Voltage1-Nom 0.2V
Voltage Tolerance-Max 3%
Min Current Limit 150mA
Nominal Output Voltage 3V
Output Voltage Accuracy 2 %
Dimensions
Height 800μm
Length 2mm
Width 2mm
Thickness 750μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
