TPS780180300DRVT
RoHS
RoHS compliant
RoHS compliantPackage 6-WDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Active Lead Free Positive CMOS Linear Voltage Regulator IC 40dB -40C~125C 1.54W 150mA
PDF
/
Buying Options
Total Price: USD $1.22
Unit Price: USD $1.2232
≥1 USD $1.2232
≥10 USD $1.09296
≥100 USD $1.037696
≥500 USD $0.852456
Inventory: 1033
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 750μm
Width 2mm
Length 2mm
Height 800μm
Technical
Output Voltage Accuracy 2 %
Input Voltage Absolute-Max 6V
Min Current Limit 150mA
Voltage Tolerance-Max 3%
Power Supply Rejection Ratio (PSRR) 40dB
Dropout Voltage1-Nom 0.2V
Dropout Voltage 200mV
PSRR 40dB ~ 15dB (10Hz ~ 1kHz)
Voltage Dropout (Max) - 0.25V @ 250mA
Current - Quiescent (Iq) 800nA
Protection Features Over Current, Over Temperature, Reverse Polarity
Min Input Voltage 2.2V
Number of Regulators 1
Voltage - Output (Min/Fixed) 1.8V 3V
Output Voltage 1 1.8V
Accuracy 3 %
Control Features Enable
Quiescent Current 500nA
Power Dissipation 1.54W
Output Configuration Positive
Max Output Current 150mA
Output Type Fixed
Output Voltage 3V
Voltage - Input (Max) 5.5V
Number of Outputs 1
Current - Supply (Max) 5μA
Pin Count 6
Base Part Number TPS780180300
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 1.54W
Packing Method TR
Subcategory Other Regulators
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 6
Surface Mount YES
Package / Case 6-WDFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
