TPS77427DGK
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Obsolete Lead Free Positive GULL WING Linear Voltage Regulator IC -40C~125C 412mW 250mA 3mm
PDF
/
Buying Options
Total Price: USD $10.57
Unit Price: USD $10.57255
≥1 USD $10.57255
≥10 USD $8.67445
≥100 USD $8.4037
≥500 USD $8.13295
≥1000 USD $7.86125
Inventory: 1834
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Subcategory Other Regulators
Max Power Dissipation 412mW
Technology PMOS
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Terminal Pitch 0.65mm
Base Part Number TPS77427
Pin Count 8
Number of Outputs 1
Voltage - Input (Max) 10V
Output Voltage 2.7V
Output Type Fixed
Max Output Current 250mA
Output Configuration Positive
Quiescent Current 125μA
Control Features Enable, Power Good
Accuracy 2 %
Output Voltage 1 2.7V
Number of Regulators 1
Min Input Voltage 2.7V
Protection Features Over Current, Over Temperature, Reverse Polarity
PSRR 55dB (1kHz)
Dropout Voltage 125mV
Dropout Voltage1-Nom 1V
Voltage Tolerance-Max 2%
Input Bias Current 92μA
Dimensions
Length 3mm
Width 3mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
